Product Description:
Brand | MSI |
---|---|
Model | MSI B450 GAMING PRO Carbon AC |
Form factor | ATX |
Sockets | AM4 |
Chipset | AMD B450 |
Supported CPU | AMD Ryzen 1st and 2nd Generation / Ryzen with Radeon Vega Graphics Processors, Athlon with Radeon Vega Graphics Processors |
RAM type | DDR4 |
RAM bus | 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466MHz |
RAM max | 64GB |
RAM slot | 4 |
PCI Express x16 slot | 1 x PCIe 3.0 x16 slot, 1 x PCIe 2.0 x16 slot, 3 x PCIe 2.0 x1 slots |
SATA port | 4 x SATA |
M.2 Slot | 2 x M.2 (Supports PCIe 2.0 x4 2242/ 2260 /2280 storage devices, Supports PCIe 3.0 x4 or PCIe 3.0 x2 and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices)) |
Audio chipset | Realtek ALC1220 |
Audio channel | 7.1-Channel |
DirectX supoort | 12 |
LAN chipset | Intel I211AT |
LAN speed | 10/100/1000Mbps |
USB Port | 1 x USB3.1 Gen 2 Type-C, 1 x USB3.1 Gen 2 Type-A, 2 x USB3.1 Gen 1, 6 x USB2.0 |
HDMI port | 1 |
Others | 1 x DisplayPort, 2 x M.2, 1 x 4-pin CPU fan connector, 1 x 4-pin water-pump-fan connector, 4 x 4-pin system fan connectors, 1 x TPM module connector, 1 x Serial Port connector, 1 x Clear CMOS jumper, 9 mounting holes, WIFI & BLUETOOTH: Intel Dual Band Wir |
Warranty | 3 year |
M.2 Slot | Yes |
